Overview KNOPPO KP HIGH POWER FULL CLOSED FIBER LASER CUTTING MACHINE WITH EXCHANGE PLATFORMS Product Description KP hig
Basic Info
Model NO. KP4020 KP6020 KP6025
Structure Type Gantry Type
Laser Classification Solid Laser
Laser Technology Laser Control Fault Cutting
Name High Power Fiber Laser Cutting Machine
Wavelength 1070nm
Sheet Cutting Area 4000*2000mm / 6000*2000mm/ 6000*2500
Laser Power 8kw/10kw/12kw/15kw/20kw
X/Y-Axis Positioning Accuracy 0.05mm
X/Y-Axis Repositioning Accuracy 0.03mm
Max. Acceleration 2.8g
Max. Linkage Speed 200m/Min
Laser Head Gemany Precitec
Laser Source Raycus / Max / Ipg
Control System Fscut8000
Servo Motor and Driver Japan Yaskawa
Water Chiller S&a
Wight 21000kg/18500kg/12500kg
Fastest Exchange Time of Platforms 50s/50s/40s
Transport Package Wooden Box
Specification 15500*4200*2400mm/15500*3700*2300mm
Trademark KNOPPO
Origin China
HS Code 8456110090
Production Capacity 500 Sets/Month
Product Description
KNOPPO KP HIGH POWER FULL CLOSED FIBER LASER CUTTING MACHINE WITH EXCHANGE PLATFORMS

Product Description


KP high power CNC fiber laser cutting machine is mainly used for thick metal sheet.8KW,10KW, 12KW, 15KW, 20KW is optional. Equipped with high power laser, it can make high power and high efficient cutting, suitable for medium and heavy metal plate. High rigidity pressure casting aluminum alloy crossbeam, it can realize high acceleration. HD monitoring, 360° without blind corner, real-time monitoring can ensure safety.

8kw 10kw 12kw 8000W 10000W 12000W High Power Fiber Laser Cutting Machine for Metal Sheet

Application

Applicable Materials

Fiber laser cutting machine can cut thick stainless steel, carbon steel, mild steel, alloy steel, galvanized steel, silicon steel, spring steel, titanium sheet, galvanized sheet, iron sheet, inox sheet, aluminum, copper, brass and other metal sheet, metal plate.
Applicable Industry
Metal working , advertising signs, decoration, arts and crafts, electronics, electric appliances, agricultural machine , metal spare parts , furniture , windows and doors working etc.Product Parameters
ModelKP6025 /KP6020/ KP4020
Laser Power8KW 10KW 12KW 15KW 20KW
Working area4000*2000mm / 6000*2000mm / 6000*2500mm
Machine overall dimensions15500*4200*2400mm/15500*3700*2300mm/10500*3700*2300mm
Machine weight21000kg/18500kg//12500kg
Max. linkage speed200m/min
Max. acceleration2.8G
Positioning accuracy0.05mm
Repositioning accuracy0.03mm
Laser Head Gemany Precitec
Laser Source MAX
Fastest exchange time of platforms 50s/50s/40s
Servo motor and driver Japan Yaskawa
Control System FSCUT8000

Detailed Photos

Gemany Precitec Laser Head

High end quality imported from Germany.

Its internal optical elements are all imported from Germany, and the automatic version cutting head uses the same motor technology as ProCutter, which can achieve fast, accurate and stable automatic focusing. LightCutter with dust-proof design has two upper and lower protective glasses to prevent the optical lens from being polluted by fusion splash, dust, metal powder and unclean gas.

.

.
  • MAX Laser Source
MAX is largest manufacturer of laser source in China , can cut carbon steel , stainless steel and aluminium etc . Good quality and long life . Suitablef for 24 hours continuous working .Strong Welding Machine BodyHigh compressive strength and high hardness. Strong shock absorption and wear resistance. Low thermal sensitivity and bed gap sensitivity reduce the loss of equipment in using, so the machine accuracy could maintain for a long time, and no deformation in a life cycle.Japan Yaskawa Servo Motor And DriverAdopting Japan Yaskawa servo motor, adopting closed-loop control method to ensure accurate positioning and dynamic response of the optimum acceleration, which makes the automatic positioning mechanism run smoothly, reliable and maintenance-free.X,Y,Z axis high power motor drive, acceleration up to 1.5G.FSCUT8000 Control SystemThe operating system can realize intelligent layout of graphics cutting and support the import of multiple graphics, optimizing cutting orders automatically, searching edges smartly and automatic positioning. Control system adopts the best logic programming and software interaction, provides stunning operation experience, effectively enhances the utilization of sheet metal and reducing waste. Simple and fast operation system, efficient and accurate cutting instructions, effectively improve the user experience.S&A Water ChillerNO.1 brand in China . Dual used , cooling laser head and laser source . also with temperature alarm .

High reliability, energy efficiency and durability

Available in 380V or 220V

Sample

Certifications

Our fiber laser cutting machine have CE certificates , all electric drawing and quality is suitable European standard .

After Sales Service

*3 years guarantee of the whole machine and we give lifetime maintenance free of charge. *Free training to make sure you master the operating of machine at our factory. * 24 hours online services through Whatsapp, Skype, Email or on the phone. *Engineers available for overseas training and after-sale services. * Friendly English version manual and operation video CD disk.
